Pictor PS22 4G GPS Vehicle Tracker (OBD II)

The PS22 is a compact 4G OBD-II GPS vehicle tracker designed for real-time vehicle tracking, diagnostics, and fleet monitoring. With built-in LTE connectivity, high-sensitivity GPS, and a rechargeable backup battery, it enables continuous v...

Get a quote Request demo
Sales 1800 123 2632

Need specs or bulk pricing? Contact our team — we usually respond within one business day.

pictor — product
PS22 2 p.png
SKU PS22

Why operators choose us

Proven deployment and support

From specs to installation, we help teams launch faster with fewer surprises.

9,00,000+
Devices sending data via our platform since 2014.
7,000+
Paying customers with live vehicles and assets since 2014.
118+
Indian cities with active customers since 2014.
12+ years
Commercial fleet deployments operating since 2014.
PS22 2 p.png
SKU: PS22 OBD GPS Tracker

The PS22 is a compact 4G OBD-II GPS vehicle tracker designed for real-time vehicle tracking, diagnostics, and fleet monitoring. With built-in LTE connectivity, high-sensitivity GPS, and a rechargeable backup battery, it enables continuous vehicle pos...

How to evaluate this product

Check fit by vehicle type, monitoring objective, installation method, and reporting needs. If you are comparing options, use our comparison and solutions pages before finalizing procurement.

Compare options See related solutions Explore technology stack

Key Highlights

  • Real-time GPS tracking
  • Trace playback history
  • User-defined Geo-fence
  • Vibration alert support
  • Disassembly alarm support
Request Pricing & Demo

Downloads

PS22 1 Manual PS22 MANUAL PS22 NEW SMS Command (1) PS22 Protocol PS22 technical specificatio
Specifications

Technical Specifications

Use this table for compatibility checks, deployment planning, and integration review.

Parameter Value
Network 2G GSM / 3G UMTS / 4G LTE
GPS Chip AT6558D
Communication Module QUECTEL
Dimensions 60mm × 46mm × 22mm
Weight 56g
Operating Voltage 9V – 35V
Working Temperature -20°C to +75°C
Battery Capacity 140mAh (Built-in Rechargeable)
Location Accuracy ≤5m
GPRS Class 12, TCP/IP Built-in GSM Module
Channel Class 20 / 50 Class
Data Upload Interval Every 10 seconds
Positioning Time - Hot Start <1 sec (Open Sky)
Positioning Time - Warm Start <15 sec
Positioning Time - Cold Start <32 sec (Open Sky)
Acquisition Sensitivity -160 dBm
Tracking Sensitivity -162 dBm
GSM Antenna FPC Antenna
GPS Antenna Built-in Ceramic Antenna
Power Status Indicator Red LED
GPS Indicator Blue LED
GSM Indicator Yellow LED
Vibration Sensor Supported
Oil/Electric Cut-off Not Supported
SOS Button Not Available
Microphone Not Available
Power Button Not Available
Working Mode Always Connected (Online Mode)
Parameter Setting SMS Command / Platform
Third Party Integration Web / APP
Features

Product Features

Features listed here should be evaluated against your route profile, risk controls, and team workflows.

# Feature
1 Real-time GPS tracking
2 Trace playback history
3 User-defined Geo-fence
4 Vibration alert support
5 Disassembly alarm support
6 Low power alarm
7 ACC detection support
8 Malfunction diagnostics
9 Remote hardware status monitoring
10 GPS & GSM signal strength monitoring (Backend)
11 Built-in backup battery
12 Web & Mobile APP platform access
13 Plug-and-play OBD II installation
14 WiFi hotspot supported
Overview

About Pictor PS22 4G GPS Vehicle Tracker (OBD II)

Pictor PS22 is a plug-and-play OBD II GPS tracking device supporting 2G/3G/4G LTE networks for reliable vehicle connectivity. It provides real-time tracking, trace playback, geo-fencing, vibration alerts, and remote diagnostics. Equipped with a QUECTEL communication module and AT6558D GPS chip, it ensures high acquisition and tracking sensitivity. The built-in 140mAh battery allows data transmission even after external power disconnection. Ideal for fleet operators, rental services, and insurance telematics applications.

FAQ

Frequently Asked Questions about Pictor PS22 4G GPS Vehicle Tracker (OBD II)

Choose based on vehicle type, deployment scale, and monitoring objective. For most buyers, the best process is pilot first, validate data quality and workflow fit, then scale with the model that gives reliable operations and manageable total cost of ownership.
A complete implementation usually includes device setup, platform configuration, alert-rule tuning, and user onboarding. The exact scope depends on your rollout size, integration needs, and whether additional modules such as fuel sensing or video are included.
Pictor PS22 4G GPS Vehicle Tracker (OBD II) can improve visibility, response time for operational exceptions, and reporting discipline. Financial and safety gains are typically strongest when teams define baseline KPIs and run consistent review and coaching workflows after go-live.
Pictor PS22 4G GPS Vehicle Tracker (OBD II) is a plug-and-play GPS tracker that connects to your vehicle's OBD-II port. No wiring required—simply plug in for instant tracking. Ideal for cars, SUVs, and light commercial vehicles with OBD ports.
Plug Pictor PS22 4G GPS Vehicle Tracker (OBD II) into the OBD-II port (usually under the dashboard). No tools or wiring needed. Power comes from the vehicle. Our app guides setup. Installation takes under 2 minutes.
Yes. Pictor PS22 4G GPS Vehicle Tracker (OBD II) provides real-time GPS tracking, trip history, geofencing, and alerts. It's ideal for small to mid-size fleets, car rental companies, and businesses needing quick deployment without installation cost.
Yes. Via the OBD port, Pictor PS22 4G GPS Vehicle Tracker (OBD II) can access engine diagnostics, fuel consumption, mileage, and fault codes. This data integrates with our fleet platform for comprehensive vehicle and driver insights.
OBD trackers are typically more affordable than wired units due to no installation. Contact Pictor for current pricing. We offer competitive rates and subscription plans for individuals and fleets.
Yes. Pictor PS22 4G GPS Vehicle Tracker (OBD II) can be unplugged easily, which is useful for moving between vehicles. For theft prevention, consider our wired trackers. OBD devices are best for fleets where vehicles are assigned to trusted drivers.
Pictor PS22 4G GPS Vehicle Tracker (OBD II) uses 4G LTE with 2G fallback, compatible with all major Indian telecom operators. It works nationwide and is tested for Indian connectivity and coverage.
