PL610 4G IoT Electronic Lock for Truck & Container
The PL610 Smart Electronic Lock is an industrial-grade GPS-enabled electronic padlock designed for container security, cargo monitoring, and high-value asset protection. It features 2G/3G/4G connectivity, GNSS multi-positioning (GPS + Beidou + GLONAS...
About PL610 4G IoT Electronic Lock for Truck & Container
The PICTOR PL610 integrates GPS tracking, RFID access control, vibration sensing, geo-fencing, and remote unlocking into a rugged electronic lock. It supports dual Micro SIM cards (single standby) and can be unlocked via SMS password, TCP command, or authorized RFID key. The device automatically locks when the hard lock hook soft rope is inserted. It sends alerts for tampering, vibration, unauthorized access attempts, geo-fence breaches, and low battery conditions.
- Remote unlock via SMS
- Unlock via TCP command (platform)
- Unlock via authorized RFID key (up to 50 keys)
- Automatic locking mechanism
- Lock/Unlock status reporting
Key highlights
Product features
Evaluate these capabilities against your route profile, risk controls, and team workflows.
- Remote unlock via SMS
- Unlock via TCP command (platform)
- Unlock via authorized RFID key (up to 50 keys)
- Automatic locking mechanism
- Lock/Unlock status reporting
- Supports 5 authorized phone numbers
- GPS + Beidou + GLONASS multi-system GNSS
- GPS + LBS fallback positioning
- Real-time location tracking
- Position accuracy < 2.5m (CEP50)
- 2G / 4G LTE Cat 1 (3G optional)
- Dual Micro SIM (single standby)
- TCP and SMS transmission
- FOTA firmware upgrade
- Tamper alert
- Unauthorized RFID swipe alert
- Wrong password alert
- Unlock alert
- Vibration alert
- Geo-fence entry alert
- Geo-fence exit alert
- Low battery alert
- Back cover opened alert
- Motor fault alert
- IP67 waterproof rating
- Engineering plastic housing
- Stainless steel hook (200KG tensile strength)
- Operating temperature -20°C to +80°C
Technical specifications
Use this table for compatibility checks, deployment planning, and integration review.
| model | PL610 |
|---|---|
| dimensions | 195mm x 114mm x 37mm |
| weight | 833g |
| material | Engineering plastic |
| waterproof_rating | IP67 |
| lock_hook | Stainless steel, 200KG tensile strength |
| battery_capacity | 10400mAh rechargeable lithium battery |
| charging | DC 5V 2A (5521 interface) |
| sim_type | Dual Micro SIM (single standby) |
| memory | 16MB |
| transmission_mode | TCP / SMS |
| working_temperature | -20°C to +80°C |
| storage_temperature | -40°C to +80°C |
| humidity_range | 5%–99% |
| gnss_module - system | GPS + Beidou + GLONASS |
| gnss_module - chipset | AT6558R |
| gnss_module - channels | 32 |
| gnss_module - cold_start | ≤32 seconds |
| gnss_module - hot_start | ≤1 second |
| gnss_module - tracking_sensitivity | -165 dBm |
| gnss_module - accuracy | <2.5m (CEP50) |
| cellular_module - gsm_module | Quectel M25 / EC200 / EC25 series |
| cellular_module - network_type | 4G LTE Cat 1 Industrial IoT module |
| electrical_performance - average_working_current | <90mA |
| electrical_performance - standby_current | <100µA |
| electrical_performance - continuous_operation_2G | Approx. 150 hours |
| electrical_performance - real_time_mode_4G | Approx. 135 hours |
Key features
- Remote unlock via SMS
- Unlock via TCP command (platform)
- Unlock via authorized RFID key (up to 50 keys)
- Automatic locking mechanism
- Lock/Unlock status reporting
- Supports 5 authorized phone numbers
- GPS + Beidou + GLONASS multi-system GNSS
- GPS + LBS fallback positioning
- Real-time location tracking
- Position accuracy < 2.5m (CEP50)
- 2G / 4G LTE Cat 1 (3G optional)
- Dual Micro SIM (single standby)
- TCP and SMS transmission
- FOTA firmware upgrade
- Tamper alert
- Unauthorized RFID swipe alert
- Wrong password alert
- Unlock alert
- Vibration alert
- Geo-fence entry alert
- Geo-fence exit alert
- Low battery alert
- Back cover opened alert
- Motor fault alert
- IP67 waterproof rating
- Engineering plastic housing
- Stainless steel hook (200KG tensile strength)
- Operating temperature -20°C to +80°C
