PL620S 4G Smart Electronic Lock with GPS for Fleet
PL620S is a 4G-enabled smart electronic GPS lock designed for real-time tracking and remote access control of containers and high-value assets. It features dual-SIM support, GNSS positioning (GPS + Beidou + GLONASS), RFID authentication, and remote u...
About PL620S 4G Smart Electronic Lock with GPS for Fleet
The PL620S Smart Electronic Lock is an industrial-grade GPS tracking lock engineered for container and asset security monitoring. It integrates 4G LTE communication, multi-constellation GNSS positioning, motion detection, RFID authentication, and remote unlock capabilities. Users can unlock the device remotely via SMS password or web platform. In the absence of a cellular network, unlocking can be performed using authorized RFID keys. The device supports real-time tracking, tamper alerts, geofencing, and lock/unlock reports. With solar charging support, stainless steel lock hook, and IP67 waterproof protection, it ensures reliable performance in harsh environments.
- 4G LTE Cat-1 industrial IoT module
- 2G fallback support
- GNSS positioning (GPS + Beidou + GLONASS)
- Dual Micro-SIM (single standby)
- TCP and SMS communication modes
Key highlights
Product features
Evaluate these capabilities against your route profile, risk controls, and team workflows.
- 4G LTE Cat-1 industrial IoT module
- 2G fallback support
- GNSS positioning (GPS + Beidou + GLONASS)
- Dual Micro-SIM (single standby)
- TCP and SMS communication modes
- Remote unlock via SMS
- Unlock via web platform
- Unlock via authorized RFID key
- Supports up to 50 authorized RFID keys
- Supports 5 authorized phone numbers
- Automatic locking mechanism
- Lock and unlock operation reports
- Hard lock hook tamper alert
- Unauthorized RFID swipe alert
- Wrong password alert
- Unlock notification
- Vibration alert
- Geo-fence entry alert
- Geo-fence exit alert
- Low battery alert
- Back cover open alert
- Motor fault alert
- 10400mAh rechargeable lithium battery
- Solar charging support
- IP67 waterproof rating
- Stainless steel lock hook (200KG tensile resistance)
- Strong magnetic mounting
- 3-axis acceleration sensor
Technical specifications
Use this table for compatibility checks, deployment planning, and integration review.
| dimensions_mm - length | 195 |
|---|---|
| dimensions_mm - width | 114 |
| dimensions_mm - height | 37 |
| weight_g | 833 |
| material | Engineering plastic |
| battery_capacity_mAh | 10400 |
| waterproof_rating | IP67 |
| working_temperature | -20°C to +80°C |
| storage_temperature | -40°C to +80°C |
| humidity_range | 5%–99% |
| average_working_current | <65mA |
| standby_current | <100uA |
| charging_specification | DC 5V / 2A (5521 interface) |
| memory | 16MB |
| motion_sensor | 3D acceleration sensor |
| antenna | Built-in GSM and GPS antenna |
| cellular_module - type | 4G LTE Cat-1 industrial IoT module |
| cellular_module - gsm_module | Quectel M25, EC200 series, EC25 series |
| cellular_module - transmission_mode | TCP (cellular network), SMS |
| gnss_module - chipset | AT6558R |
| gnss_module - system | GPS, Beidou, GLONASS |
| gnss_module - channels | 32 |
| gnss_module - cold_start_time | ≤32s |
| gnss_module - hot_start_time | ≤1s |
| gnss_module - tracking_sensitivity | -165dBm |
| gnss_module - cold_start_sensitivity | -148dBm |
| gnss_module - position_accuracy | <2.5m (CEP50) |
| working_duration - 2G_continuous_operation_hours | 160 |
| working_duration - 4G_real_time_mode_hours | 140 |
| led_indicators - gsm | Red LED - Cellular network status |
| led_indicators - gps | Green LED - GPS fix status |
| led_indicators - low_battery | Yellow LED |
| led_indicators - charging | Red/Green LED |
Key features
- 4G LTE Cat-1 industrial IoT module
- 2G fallback support
- GNSS positioning (GPS + Beidou + GLONASS)
- Dual Micro-SIM (single standby)
- TCP and SMS communication modes
- Remote unlock via SMS
- Unlock via web platform
- Unlock via authorized RFID key
- Supports up to 50 authorized RFID keys
- Supports 5 authorized phone numbers
- Automatic locking mechanism
- Lock and unlock operation reports
- Hard lock hook tamper alert
- Unauthorized RFID swipe alert
- Wrong password alert
- Unlock notification
- Vibration alert
- Geo-fence entry alert
- Geo-fence exit alert
- Low battery alert
- Back cover open alert
- Motor fault alert
- 10400mAh rechargeable lithium battery
- Solar charging support
- IP67 waterproof rating
- Stainless steel lock hook (200KG tensile resistance)
- Strong magnetic mounting
- 3-axis acceleration sensor
