PT06 4G Wired GPS Vehicle Tracker for Fleet Tracking
PT06 is a compact GPS vehicle tracking device with real-time tracking, geo-fencing, engine cut-off, and multi-alarm features, designed for cars and electric vehicles.
About PT06 4G Wired GPS Vehicle Tracker for Fleet Tracking
The PICTOR PT06 GPS Tracker is a high-performance vehicle tracking solution designed for real-time location monitoring and fleet management. Supporting wide voltage input (9–90V), it is suitable for cars and electric bikes. The device integrates tracking, security alerts, and remote engine control features. It supports web-based tracking and mobile app monitoring, ensuring complete vehicle visibility and anti-theft protection.
- Live GPS location monitoring via web platform and mobile app
- Detects vehicle ignition ON/OFF status
- Set virtual boundaries and receive alerts when breached
- Notifies when vehicle exceeds preset speed limit
- Alerts when device battery voltage is low
Key highlights
Product features
Evaluate these capabilities against your route profile, risk controls, and team workflows.
- Live GPS location monitoring via web platform and mobile app
- Detects vehicle ignition ON/OFF status
- Set virtual boundaries and receive alerts when breached
- Notifies when vehicle exceeds preset speed limit
- Alerts when device battery voltage is low
- Triggers alert when unauthorized movement is detected
- Sends notification if abnormal vibration occurs
- Alarm triggered if device wiring is tampered
- Receives alerts via SMS commands
- View historical route tracking data
- Fuel/power cut-off using external relay
Technical specifications
Use this table for compatibility checks, deployment planning, and integration review.
| Brand | PICTOR |
|---|---|
| Model | PT06 |
| Device Type | GPS Vehicle Tracker |
| Voltage Input Range | 9V – 90V |
| Network Type | GSM |
| Tracking Platform | http://www.gwgps12580.com/ |
| Mobile Application | CarHere APP |
| Default Login Password | 123456 |
| SIM Requirement | GPRS data + SMS service enabled |
| Relay Compatibility | 5V (Electric Bike), 12V (Car) |
| Power Supply Type | External power with internal backup battery |
| Red LED Indicator | Power supply status indication |
| Yellow LED Indicator | GSM signal status indication |
| Blue LED Indicator | GPS signal status indication |
| Red Wire | Positive (9–90V) |
| Black Wire | Negative (Ground) |
| Orange Wire | ACC line connection |
| Yellow Wire | Relay connection for engine cut-off |
| GSM Status - Quick Blink | Searching GSM signal |
| GSM Status - Slow Blink | Normal working |
| GSM Status - Off | GSM signal failed or sleeping |
| GPS Status - Quick Blink | Searching GPS signal |
| GPS Status - Slow Blink | Normal working |
| GPS Status - Off | GPS signal failed or sleeping |
Key features
- Live GPS location monitoring via web platform and mobile app
- Detects vehicle ignition ON/OFF status
- Set virtual boundaries and receive alerts when breached
- Notifies when vehicle exceeds preset speed limit
- Alerts when device battery voltage is low
- Triggers alert when unauthorized movement is detected
- Sends notification if abnormal vibration occurs
- Alarm triggered if device wiring is tampered
- Receives alerts via SMS commands
- View historical route tracking data
- Fuel/power cut-off using external relay
