PT100 8-Wire 4G GPS Fleet Tracker for Vehicle Monitoring
PT100 is a compact 4G LTE-based vehicle GPS tracker with GPS+BDS dual-mode positioning, designed for fleet monitoring, anti-theft protection, and vehicle supervision applications.
About PT100 8-Wire 4G GPS Fleet Tracker for Vehicle Monitoring
PT100 is a high-precision 4G vehicle tracking device equipped with GPS+BDS dual-mode positioning technology, offering up to 2.5 meters accuracy. It supports real-time tracking, geo-fencing, driving behavior monitoring, and remote fuel/power cut-off. With built-in 16Mb flash memory, the device stores location data when out of network coverage and automatically retransmits once connectivity is restored. Its ultra-mini design allows easy and hidden installation. With IP66 waterproof protection and wide 9–100V power input, PT100 is suitable for cars, trucks, commercial fleets, and shared mobility vehicles.
- Real-time / Time Interval / Distance Based / SMS Tracking / Platform Tracking
- Harsh Acceleration / Harsh Braking / Harsh Turning / Fatigue Driving / Idling Detection
- SOS Alarm / Speeding Alarm / Geo-Fence Alarm / GPS Signal Loss Alarm / Impact Alarm / Towing Alarm / Low Battery Alarm / External Power Cut Alarm / Fuel Theft Alarm / Low Fuel Alarm
- Supports Capacitive & Ultrasonic Fuel Sensors (Analog or RS232)
- Remote Fuel/Electricity Cut-Off via Output
Key highlights
Product features
Evaluate these capabilities against your route profile, risk controls, and team workflows.
- Real-time / Time Interval / Distance Based / SMS Tracking / Platform Tracking
- Harsh Acceleration / Harsh Braking / Harsh Turning / Fatigue Driving / Idling Detection
- SOS Alarm / Speeding Alarm / Geo-Fence Alarm / GPS Signal Loss Alarm / Impact Alarm / Towing Alarm / Low Battery Alarm / External Power Cut Alarm / Fuel Theft Alarm / Low Fuel Alarm
- Supports Capacitive & Ultrasonic Fuel Sensors (Analog or RS232)
- Remote Fuel/Electricity Cut-Off via Output
- Offline Data Storage with Auto Resend
- Dual Server Support
- FOTA (Firmware Over-the-Air)
- 2 Digital Inputs (Configurable as Analog), 1 Output, Micro USB, Optional Microphone
Technical specifications
Use this table for compatibility checks, deployment planning, and integration review.
| Model | PT100 |
|---|---|
| Network | 4G LTE Cat-1 / Cat-M / Cat-NB (variant dependent) |
| Positioning | GPS + BDS Dual Mode |
| Positioning Accuracy | 2.5 meters |
| GPS Sensitivity | -165dB |
| Dimensions | 80 × 34 × 15 mm |
| Weight | Approx. 48g |
| Input Voltage | DC 9–100V |
| Waterproof Rating | IP66 |
| Battery | Built-in 55mAh |
| Battery Backup | Up to 30 minutes |
| Flash Memory | 16Mb |
| Operating Temperature | -20°C to 80°C |
| Standby Power Consumption | 51mA/h |
| MCU | Cortex-M4 AT32F415CBT7 |
| SIM Type | Nano SIM |
| Antenna | Built-in GSM FPC + Ceramic GPS Antenna (25×25×4mm) |
| Sensor | 3D Accelerometer |
| LED Indicators | Blue (GPS) + Green (Network) |
| LTE Bands | Regional variants available (CN / EU / NA / SA / Global) |
| GSM Bands | 850/900/1800/1900 MHz (variant dependent) |
| Analog Input Range | 0–6.6V (AD1/AD2 configurable) |
| Digital Inputs | 2 configurable (High/Low trigger) |
| Output Type | Open-drain output, >500mA, 100V withstand |
| Serial Interface | RS232/TTL (customizable) |
| Fuel Sensor Compatibility | Ultrasonic (100cm/250cm) & Capacitive Sensors |
| Speed Limiter Support | Configurable via SMS or Parameter Editor |
Key features
- Real-time / Time Interval / Distance Based / SMS Tracking / Platform Tracking
- Harsh Acceleration / Harsh Braking / Harsh Turning / Fatigue Driving / Idling Detection
- SOS Alarm / Speeding Alarm / Geo-Fence Alarm / GPS Signal Loss Alarm / Impact Alarm / Towing Alarm / Low Battery Alarm / External Power Cut Alarm / Fuel Theft Alarm / Low Fuel Alarm
- Supports Capacitive & Ultrasonic Fuel Sensors (Analog or RS232)
- Remote Fuel/Electricity Cut-Off via Output
- Offline Data Storage with Auto Resend
- Dual Server Support
- FOTA (Firmware Over-the-Air)
- 2 Digital Inputs (Configurable as Analog), 1 Output, Micro USB, Optional Microphone
