PIOTOR PL610 4G GPS Smart Electronic Container Lock

The PL610 Smart Electronic Lock is an industrial-grade GPS-enabled electronic padlock designed for container security, cargo monitoring, and high-value asset protection. It features 2G/3G/4G connectivity, GNSS multi-positioning (GPS + Beido...

Get a quote Request demo

Sales 1800 123 2632

Need specs or bulk pricing? Contact our team — we usually respond within one business day.

pictor — product

SKU PL610

Why operators choose us

Proven deployment and support

From specs to installation, we help teams launch faster with fewer surprises.

9,00,000+

Devices sending data via our platform since 2014.

7,000+

Paying customers with live vehicles and assets since 2014.

118+

Indian cities with active customers since 2014.

12+ years

Commercial fleet deployments operating since 2014.

SKU: PL610 E-Locks

How to evaluate this product

Check fit by vehicle type, monitoring objective, installation method, and reporting needs. If you are comparing options, use our comparison and solutions pages before finalizing procurement.

Compare options See related solutions Explore technology stack

Key Highlights

Remote unlock via SMS
Unlock via TCP command (platform)
Unlock via authorized RFID key (up to 50 keys)
Automatic locking mechanism
Lock/Unlock status reporting

Request Pricing & Demo

Downloads

PL610 MANUAL PL610 PROTOCOL MANUAL

Specifications

Technical Specifications

Use this table for compatibility checks, deployment planning, and integration review.

Parameter	Value
model	PL610
dimensions	195mm x 114mm x 37mm
weight	833g
material	Engineering plastic
waterproof_rating	IP67
lock_hook	Stainless steel, 200KG tensile strength
battery_capacity	10400mAh rechargeable lithium battery
charging	DC 5V 2A (5521 interface)
sim_type	Dual Micro SIM (single standby)
memory	16MB
transmission_mode	TCP / SMS
working_temperature	-20°C to +80°C
storage_temperature	-40°C to +80°C
humidity_range	5%–99%
gnss_module - system	GPS + Beidou + GLONASS
gnss_module - chipset	AT6558R
gnss_module - channels	32
gnss_module - cold_start	≤32 seconds
gnss_module - hot_start	≤1 second
gnss_module - tracking_sensitivity	-165 dBm
gnss_module - accuracy	<2.5m (CEP50)
cellular_module - gsm_module	Quectel M25 / EC200 / EC25 series
cellular_module - network_type	4G LTE Cat 1 Industrial IoT module
electrical_performance - average_working_current	<90mA
electrical_performance - standby_current	<100µA
electrical_performance - continuous_operation_2G	Approx. 150 hours
electrical_performance - real_time_mode_4G	Approx. 135 hours

Features

Product Features

Features listed here should be evaluated against your route profile, risk controls, and team workflows.

#	Feature
1	Remote unlock via SMS
2	Unlock via TCP command (platform)
3	Unlock via authorized RFID key (up to 50 keys)
4	Automatic locking mechanism
5	Lock/Unlock status reporting
6	Supports 5 authorized phone numbers
7	GPS + Beidou + GLONASS multi-system GNSS
8	GPS + LBS fallback positioning
9	Real-time location tracking
10	Position accuracy < 2.5m (CEP50)
11	2G / 4G LTE Cat 1 (3G optional)
12	Dual Micro SIM (single standby)
13	TCP and SMS transmission
14	FOTA firmware upgrade
15	Tamper alert
16	Unauthorized RFID swipe alert
17	Wrong password alert
18	Unlock alert
19	Vibration alert
20	Geo-fence entry alert
21	Geo-fence exit alert
22	Low battery alert
23	Back cover opened alert
24	Motor fault alert
25	IP67 waterproof rating
26	Engineering plastic housing
27	Stainless steel hook (200KG tensile strength)
28	Operating temperature -20°C to +80°C

Overview

About PIOTOR PL610 4G GPS Smart Electronic Container Lock

The PIOTOR PL610 integrates GPS tracking, RFID access control, vibration sensing, geo-fencing, and remote unlocking into a rugged electronic lock. It supports dual Micro SIM cards (single standby) and can be unlocked via SMS password, TCP command, or authorized RFID key. The device automatically locks when the hard lock hook soft rope is inserted. It sends alerts for tampering, vibration, unauthorized access attempts, geo-fence breaches, and low battery conditions.

FAQ

Frequently Asked Questions about PIOTOR PL610 4G GPS Smart Electronic Container Lock

Choose based on vehicle type, deployment scale, and monitoring objective. For most buyers, the best process is pilot first, validate data quality and workflow fit, then scale with the model that gives reliable operations and manageable total cost of ownership.

A complete implementation usually includes device setup, platform configuration, alert-rule tuning, and user onboarding. The exact scope depends on your rollout size, integration needs, and whether additional modules such as fuel sensing or video are included.

PIOTOR PL610 4G GPS Smart Electronic Container Lock can improve visibility, response time for operational exceptions, and reporting discipline. Financial and safety gains are typically strongest when teams define baseline KPIs and run consistent review and coaching workflows after go-live.

PIOTOR PL610 4G GPS Smart Electronic Container Lock is an electronic lock for shipping containers and cargo. It provides real-time tracking, door-open alerts, and tamper detection. Used by logistics companies and exporters for secure container monitoring across India and internationally.

PIOTOR PL610 4G GPS Smart Electronic Container Lock locks the container door and sends instant alerts if the lock is tampered with or opened. GPS tracking shows container location. Fleet managers get real-time visibility for cargo security.

Yes. Our E-Locks work with global cellular networks for tracking across borders. Used for export-import, port-to-port, and inland logistics. Contact us for coverage and roaming options.

Battery life varies by model and usage—typically months to a year. Low-battery alerts notify before replacement. Some models support solar or external power for long-haul shipments.

E-Lock pricing includes hardware and connectivity. Contact Pictor for a quote. We offer solutions for logistics companies, exporters, and freight forwarders. Volume pricing for fleet deployments.

Yes. PIOTOR PL610 4G GPS Smart Electronic Container Lock includes built-in GPS for live tracking. View container location on a map, get route history, and set geofences. Integrates with our fleet management platform.

Installation is done on the container door. Our technicians or trained partners can install at your yard or port. Setup is typically quick and can often be completed in a short yard or gate turnaround window. We provide installation guidelines and support.
