PL620 Smart Electronic Lock

PL620 is a 2G/3G/4G GPS-enabled smart electronic lock designed for real-time asset and container security monitoring. It integrates GNSS positioning, RFID authentication, remote unlocking, tamper detection, geo-fencing, and intelligent aler...

Get a quote Request demo

Sales 1800 123 2632

Need specs or bulk pricing? Contact our team — we usually respond within one business day.

pictor — product

SKU PL620

Why operators choose us

Proven deployment and support

From specs to installation, we help teams launch faster with fewer surprises.

9,00,000+

Devices sending data via our platform since 2014.

7,000+

Paying customers with live vehicles and assets since 2014.

118+

Indian cities with active customers since 2014.

12+ years

Commercial fleet deployments operating since 2014.

SKU: PL620 E-Locks

How to evaluate this product

Check fit by vehicle type, monitoring objective, installation method, and reporting needs. If you are comparing options, use our comparison and solutions pages before finalizing procurement.

Compare options See related solutions Explore technology stack

Key Highlights

2G / 3G (Optional) / 4G LTE Connectivity
GPS + Beidou + GLONASS Multi-Positioning
Built-in 10400mAh Rechargeable Battery
Remote Unlock via SMS / TCP Command
Unlock via Authorized RFID Keys (Up to 50 Keys)

Request Pricing & Demo

Downloads

PL620 MANUAL PL620 PROTOCOL MANUAL

Specifications

Technical Specifications

Use this table for compatibility checks, deployment planning, and integration review.

Parameter	Value
model	PL620
dimensions	195mm x 114mm x 37mm
weight	833g
material	Engineering Plastic
waterproof_rating	IP67
battery_capacity	10400mAh Rechargeable Lithium Battery
working_temperature	-20°C to +80°C
storage_temperature	-40°C to +80°C
humidity	5% – 99%
charging	DC 5V / 2A (5521 Interface)
memory	16MB
motion_sensor	3D Acceleration Sensor
lock_hook	Stainless Steel, 200KG Tensile Resistance
cellular - network	4G LTE Cat-1 Industrial IoT Module
cellular - transmission_mode	TCP (Cellular Network) / SMS
cellular - sim_support	Dual Micro SIM, Single Standby
gnss - system	GPS + Beidou + GLONASS
gnss - chipset	AT6558R
gnss - channels	32
gnss - cold_start	≤32 seconds
gnss - hot_start	≤1 second
gnss - tracking_sensitivity	-165dBm
gnss - accuracy	<2.5m (CEP50)
power_performance - average_working_current	<90mA
power_performance - standby_current	<100µA
power_performance - working_hours_2g	150 hours continuous full load
power_performance - working_hours_4g	135 hours real-time mode
led_indicators	GSM (Red) – Cellular Network Status, GPS (Green) – GPS Fix Status, LVS (Yellow) – Low Battery Status, CHG (Red/Green) – Charging Status

Features

Product Features

Features listed here should be evaluated against your route profile, risk controls, and team workflows.

#	Feature
1	2G / 3G (Optional) / 4G LTE Connectivity
2	GPS + Beidou + GLONASS Multi-Positioning
3	Built-in 10400mAh Rechargeable Battery
4	Remote Unlock via SMS / TCP Command
5	Unlock via Authorized RFID Keys (Up to 50 Keys)
6	Dual Micro SIM (Single Standby)
7	3-Axis Motion & Vibration Sensor
8	Up to 10 Polygon Geo-Fences
9	9 Intelligent Alerts (Tamper, Vibration, Low Battery, Geo Entry/Exit, Wrong Password, etc.)
10	Automatic Locking Mechanism
11	IP67 Waterproof Design
12	OTA Firmware Upgrade (FOTA)
13	Bluetooth (Optional)
14	Lock & Unlock Operation Reports
15	Strong Magnetic Back Support

Overview

About PL620 Smart Electronic Lock

PL620 Smart Electronic Lock is a heavy-duty GPS tracking lock engineered for containers, cargo trucks, trailers, and movable assets. It supports real-time tracking via GPS + Beidou + GLONASS and communicates over cellular networks using TCP or SMS. The device can be unlocked remotely through SMS password or platform command, and locally using authorized RFID keys. It features automatic locking, vibration detection, geo-fencing alerts, dual SIM support, OTA firmware upgrade, and a stainless-steel lock hook with 200KG tensile resistance.

FAQ

Frequently Asked Questions about PL620 Smart Electronic Lock

Choose based on vehicle type, deployment scale, and monitoring objective. For most buyers, the best process is pilot first, validate data quality and workflow fit, then scale with the model that gives reliable operations and manageable total cost of ownership.

A complete implementation usually includes device setup, platform configuration, alert-rule tuning, and user onboarding. The exact scope depends on your rollout size, integration needs, and whether additional modules such as fuel sensing or video are included.

PL620 Smart Electronic Lock can improve visibility, response time for operational exceptions, and reporting discipline. Financial and safety gains are typically strongest when teams define baseline KPIs and run consistent review and coaching workflows after go-live.

PL620 Smart Electronic Lock is an electronic lock for shipping containers and cargo. It provides real-time tracking, door-open alerts, and tamper detection. Used by logistics companies and exporters for secure container monitoring across India and internationally.

PL620 Smart Electronic Lock locks the container door and sends instant alerts if the lock is tampered with or opened. GPS tracking shows container location. Fleet managers get real-time visibility for cargo security.

Yes. Our E-Locks work with global cellular networks for tracking across borders. Used for export-import, port-to-port, and inland logistics. Contact us for coverage and roaming options.

Battery life varies by model and usage—typically months to a year. Low-battery alerts notify before replacement. Some models support solar or external power for long-haul shipments.

E-Lock pricing includes hardware and connectivity. Contact Pictor for a quote. We offer solutions for logistics companies, exporters, and freight forwarders. Volume pricing for fleet deployments.

Yes. PL620 Smart Electronic Lock includes built-in GPS for live tracking. View container location on a map, get route history, and set geofences. Integrates with our fleet management platform.

Installation is done on the container door. Our technicians or trained partners can install at your yard or port. Setup is typically quick and can often be completed in a short yard or gate turnaround window. We provide installation guidelines and support.
