PL610S 4G Smart Electronic GPS Lock

PL610S is a 4G smart electronic GPS lock designed for real-time tracking and secure container or asset monitoring. It features GNSS positioning (GPS + Beidou + GLONASS), RFID authentication, remote unlocking via SMS or app, dual SIM support...

Get a quote Request demo

Sales 1800 123 2632

Need specs or bulk pricing? Contact our team — we usually respond within one business day.

pictor — product

SKU PL610S

Why operators choose us

Proven deployment and support

From specs to installation, we help teams launch faster with fewer surprises.

9,00,000+

Devices sending data via our platform since 2014.

7,000+

Paying customers with live vehicles and assets since 2014.

118+

Indian cities with active customers since 2014.

12+ years

Commercial fleet deployments operating since 2014.

SKU: PL610S E-Locks

How to evaluate this product

Check fit by vehicle type, monitoring objective, installation method, and reporting needs. If you are comparing options, use our comparison and solutions pages before finalizing procurement.

Compare options See related solutions Explore technology stack

Key Highlights

4G LTE Cat1 Industrial IoT Module
GNSS Positioning: GPS + Beidou + GLONASS
Dual Micro SIM (Single Standby)
10400mAh Rechargeable Lithium Battery
Solar Panel Charging Support

Request Pricing & Demo

Downloads

PL610S Elock User Manual PL610S User Protocol

Specifications

Technical Specifications

Use this table for compatibility checks, deployment planning, and integration review.

Parameter	Value
size	195mm x 114mm x 37mm
weight	833g (Including hard lock hook soft rope)
material	Engineering Plastic
waterproof_rating	IP67
working_temperature	-20°C to +80°C
storage_temperature	-40°C to +80°C
humidity_range	5% – 99%
battery_capacity	10400mAh Rechargeable Lithium Battery
average_working_current	<65mA
standby_current	<100µA
memory	16MB
motion_sensor	3D Acceleration Sensor
antenna	Built-in GSM/GPS Antenna
lock_hook_material	Stainless Steel
lock_hook_tensile_strength	200KG
charging_specification	DC 5V, 2A (5521 Interface)
transmission_mode	TCP (Cellular Network) / SMS
cellular_module - type	4G LTE Cat1 Industrial IoT Module
cellular_module - sim_support	Dual Micro SIM (Single Standby Mode)
cellular_module - network_support	LTE FDD, LTE TDD, WCDMA, GSM/EDGE
gnss_module - system	GPS + Beidou + GLONASS
gnss_module - chipset	AT6558R
gnss_module - receiver	32 Channel
gnss_module - cold_start	≤32s
gnss_module - hot_start	≤1s
gnss_module - tracking_sensitivity	-165dBm
gnss_module - cold_start_sensitivity	-148dBm
gnss_module - positioning_accuracy	<2.5m (CEP50)
working_hours - 2g_mode	Up to 160 hours continuous operation
working_hours - 4g_mode	Up to 140 hours real-time working

Features

Product Features

Features listed here should be evaluated against your route profile, risk controls, and team workflows.

#	Feature
1	4G LTE Cat1 Industrial IoT Module
2	GNSS Positioning: GPS + Beidou + GLONASS
3	Dual Micro SIM (Single Standby)
4	10400mAh Rechargeable Lithium Battery
5	Solar Panel Charging Support
6	Remote Unlock via SMS and Web Platform
7	Unlock via Authorized RFID Keys (Up to 50 Keys)
8	Automatic Locking Mechanism
9	3-Axis Acceleration Sensor (Vibration Detection)
10	10 Polygon Geo-Fences
11	5 Authorized Phone Numbers
12	9 Intelligent Alert Types
13	Buzzer and LED Status Indicators
14	FOTA (Firmware Over-The-Air Upgrade)
15	IP67 Waterproof Design
16	Stainless Steel Lock Hook (200KG Tensile Resistance)

Overview

About PL610S 4G Smart Electronic GPS Lock

The PL610S Smart Electronic Lock is an industrial-grade GPS-enabled security lock for containers, trailers, and valuable assets. It supports 4G LTE Cat1 connectivity for real-time tracking and monitoring. The device can be unlocked remotely via SMS password or web platform and locally using authorized RFID keys. It automatically locks when the hard lock hook soft rope is inserted. Equipped with a 10400mAh rechargeable battery, motion detection, geo-fencing, solar charging, and tamper alerts, the PL610S ensures secure and intelligent asset protection.

FAQ

Frequently Asked Questions about PL610S 4G Smart Electronic GPS Lock

Choose based on vehicle type, deployment scale, and monitoring objective. For most buyers, the best process is pilot first, validate data quality and workflow fit, then scale with the model that gives reliable operations and manageable total cost of ownership.

A complete implementation usually includes device setup, platform configuration, alert-rule tuning, and user onboarding. The exact scope depends on your rollout size, integration needs, and whether additional modules such as fuel sensing or video are included.

PL610S 4G Smart Electronic GPS Lock can improve visibility, response time for operational exceptions, and reporting discipline. Financial and safety gains are typically strongest when teams define baseline KPIs and run consistent review and coaching workflows after go-live.

PL610S 4G Smart Electronic GPS Lock is an electronic lock for shipping containers and cargo. It provides real-time tracking, door-open alerts, and tamper detection. Used by logistics companies and exporters for secure container monitoring across India and internationally.

PL610S 4G Smart Electronic GPS Lock locks the container door and sends instant alerts if the lock is tampered with or opened. GPS tracking shows container location. Fleet managers get real-time visibility for cargo security.

Yes. Our E-Locks work with global cellular networks for tracking across borders. Used for export-import, port-to-port, and inland logistics. Contact us for coverage and roaming options.

Battery life varies by model and usage—typically months to a year. Low-battery alerts notify before replacement. Some models support solar or external power for long-haul shipments.

E-Lock pricing includes hardware and connectivity. Contact Pictor for a quote. We offer solutions for logistics companies, exporters, and freight forwarders. Volume pricing for fleet deployments.

Yes. PL610S 4G Smart Electronic GPS Lock includes built-in GPS for live tracking. View container location on a map, get route history, and set geofences. Integrates with our fleet management platform.

Installation is done on the container door. Our technicians or trained partners can install at your yard or port. Setup is typically quick and can often be completed in a short yard or gate turnaround window. We provide installation guidelines and support.
