Product Wireless Asset Tracker

G57 2G Asset GPS Tracker

Compact magnetic 2G GPS asset tracker with 3000mAh battery, real-time tracking, geo-fence alerts, and remote voice monitoring support.

Get a quote Request demo

Sales 1800 123 2632

Need specs or bulk pricing? Contact our team — we usually respond within one business day.

pictor — product

SKU G57 2G

Why operators choose us

Proven deployment and support

From specs to installation, we help teams launch faster with fewer surprises.

9,00,000+

Devices sending data via our platform since 2014.

7,000+

Paying customers with live vehicles and assets since 2014.

118+

Indian cities with active customers since 2014.

12+ years

Commercial fleet deployments operating since 2014.

SKU: G57 2G Wireless Asset Tracker

Compact magnetic 2G GPS asset tracker with 3000mAh battery, real-time tracking, geo-fence alerts, and remote voice monitoring support.

How to evaluate this product

Check fit by vehicle type, monitoring objective, installation method, and reporting needs. If you are comparing options, use our comparison and solutions pages before finalizing procurement.

Compare options See related solutions Explore technology stack

Key Highlights

GPS L1, 1575.42 MHz C/A code
< 10 meters
-165 dBm
-148 dBm
Real-time mode, Power-saving mode (default), Clock mode, Interval mode

Request Pricing & Demo

Downloads

A G57 G5A 45 G User Manual (1) G57 Serials Communicate Protocol

Specifications

Technical Specifications

Use this table for compatibility checks, deployment planning, and integration review.

Parameter	Value
Model	G57 2G
Dimensions	69 × 43 × 20 mm
Network	2G GSM
GSM Frequency	850/900/1800/1900 MHz
Battery Capacity	3000mAh Rechargeable Lithium Battery
Standby Time	Up to 1–90 days (depending on activity and mode)
Charging Voltage	5V DC
Working Current	100uA – 100mA
Operating Temperature	-20°C to +70°C
Memory	32 + 32 Mb
Antenna	Built-in quad-band GSM antenna + GPS ceramic antenna
Chipset	MTK6261 (GSM) + AT6558R (GPS)
GSM Max Output Power	GSM850/900: 33±3 dBm; GSM1800/1900: 30±3 dBm
Max Frequency Error	±0.1 ppm
Receive Sensitivity	Class II RBER2% (-102 dBm)
GPS Channels	66 Channels
TTFF (Open Sky)	Hot Start ≤1 sec; Cold Start ≤32 sec
Phase Error	RMSPE <5, PPE <20

Features

Product Features

Features listed here should be evaluated against your route profile, risk controls, and team workflows.

#	Feature
1	GPS L1, 1575.42 MHz C/A code
2	< 10 meters
3	-165 dBm
4	-148 dBm
5	Real-time mode, Power-saving mode (default), Clock mode, Interval mode
6	Geo-fence alarm, Low battery alarm, Vibration alarm
7	One-way remote voice listen via SIM call
8	GPRS Class 12, TCP/IP
9	Strong built-in magnet for concealed mounting
10	Green (GSM), Blue (GPS), Red (Power/Charging)

Overview

About G57 2G Asset GPS Tracker

The G57 2G Asset GPS Tracker is a compact and rechargeable tracking device designed for vehicles, assets, and personal monitoring. Supporting quad-band 2G GSM connectivity, it provides real-time location tracking through an online platform or mobile app. The device features a built-in 3000mAh lithium battery, offering standby time depending on activity and working mode. With strong magnetic mounting, it can be easily hidden inside vehicles or attached to metallic assets. It supports geo-fencing, vibration alerts, low battery alarms, and remote one-way voice listening via SIM card call.

FAQ

Frequently Asked Questions about G57 2G Asset GPS Tracker

Choose based on vehicle type, deployment scale, and monitoring objective. For most buyers, the best process is pilot first, validate data quality and workflow fit, then scale with the model that gives reliable operations and manageable total cost of ownership.

A complete implementation usually includes device setup, platform configuration, alert-rule tuning, and user onboarding. The exact scope depends on your rollout size, integration needs, and whether additional modules such as fuel sensing or video are included.

G57 2G Asset GPS Tracker can improve visibility, response time for operational exceptions, and reporting discipline. Financial and safety gains are typically strongest when teams define baseline KPIs and run consistent review and coaching workflows after go-live.

G57 2G Asset GPS Tracker is a battery-powered GPS tracker for assets that don't have a power source—generators, trailers, construction equipment, containers. No wiring required; place and track via our platform.

Battery life depends on reporting frequency and motion. Typical range is 3–12 months. Configure update intervals to balance battery life and tracking accuracy. Low-battery alerts notify before replacement.

Track generators, trailers, shipping containers, construction equipment, two-wheelers, and any movable asset. Ideal for rental companies, logistics, and businesses with unattended assets.

Yes. Get alerts when the asset moves, leaves a geofence, or is tampered with. Motion-based tracking can increase update frequency when moving and reduce it when stationary to save battery.

Pricing includes hardware and connectivity. Contact Pictor for a quote. We offer competitive rates for single units and volume discounts for fleet deployments.

Yes. G57 2G Asset GPS Tracker is built for rugged conditions—dust, moisture, and temperature extremes. IP-rated enclosures protect the unit. Suitable for construction sites, ports, and industrial environments.

Yes. Set geofences for yards, sites, or depots. Receive alerts when assets enter or leave. Useful for theft prevention and asset utilisation monitoring.
